| Interface | 1× SC/APC GPON Port 1× 10/100/1000 Mbps WAN/LAN Port 3× 10/100/1000 Mbps LAN Ports 1× FXS Port 1× USB 2.0 Port |
|---|---|
| Botão | WPS/Wi-Fi Button RESET Button Power On/Off Button |
| Fonte de Alimentação Externa | 12V/1.5A |
| Taxa de Dados | Downstream Speeds: 2.488 Gbps (GPON) Upstream Speeds: 1.244 Gbps (GPON)§ |
| Antena | 4 External Antennas |
| Padrões Wireless | IEEE 802.11a/n/ac/ax 5 GHz IEEE 802.11b/g/n/ax 2.4 GHz |
|---|---|
| Frequência | 2.4 GHz and 5 GHz |
| Taxa de Sinal | AX1800 5 GHz: Up to 1201 Mbps (HE80) 2.4 GHz: Up to 574 Mbps (HE40)* |
| Funções Wireless | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Segurança Wireless | WPA/WPA2/WPA3 Encryptions |
| Potência de Transmissão | CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) |
| Multi-SSID | 2× 5 GHz Multi-SSID 2× 2.4 GHz Multi-SSID |
| Agendamento Wireless | Support 2.4 GHz and 5 GHz Wireless Schedule |
| Mesh Technology | EasyMesh Compatible, and support 802.11k/v/r |
| QoS | Hardware QoS, Flow Classification |
|---|---|
| Características Avançadas | Parental Controls, Network Address Translation(NAT), Port Mapping(Grouping), Static Routing, DNS Relay, DDNS, IGMP V1/V2/V3 |
| Segurança | NAT Firewall, Access Control, MAC/IP/URL Filtering, IP and MAC Address Binding, Defense “Denial of Service (DoS), SYNFlooding, Ping of Death" |
| Gerenciamento | Local management: WebGUI, Aginet app (for end users) Remote management: Aginet ACS, OMCI, TR-069/TR-369, TR-098, TR-181, TR-111,TR-143 for service providers Aginet APP for end user (need to log in wtih TP-Link ID and bind your device to it) Cloud management: TP-Link Aginet Unified Cloud (TAUC) |
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| Redirecionamento de Portas | Virtual Server, Port Triggering, DMZ, ALG, UPnP |
| DNS Dinâmico | DynDns, NO-IP |
| VPN Pass-Through | PPTP, L2TP, IPSec Pass-through |
| Protocolos | IPv4, IPv6 |
| VPN Server | PPTP VPN, IPSec VPN , OpenVPN |
